Kirjeldus
Tehnilised andmed
Base Attributes
| Manufacturer Code | DS-7616NXI-I2/16P/S(E) |
|---|---|
| Net Weight | 2.38 |
| Gross Weight | 3.55 |
Key Parameter
| Wireless Network | N/A |
|---|---|
| AI | Yes |
| IP Channel Number | 16-ch |
| HDD Interface | 2 |
| PoE Interface | 16-ch |
| Decoding Capability | 16-ch@1080p |
| External Interface | HDMI, CVBS, VGA |
| RAID | Ei |
| Chassis | 1U |
Video and Audio
| Incoming Bandwidth | 160 Mbps |
|---|---|
| Outgoing Bandwidth | 256 Mbps |
| Video Output Mode | HDMI/VGA independent output |
Decoding
| Decoding Format | H.265+/H.265/H.264+/H.264 |
|---|
Network
| Network Interface | 1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
|---|---|
| Remote Connection | 128 |
General
| Kaubamärgid | HIKVISION |
|---|---|
| Power Supply | 100 to 240 VAC, 50 to 60 Hz |
| Working Humidity | 10% to 90% |
| Working Temperature | -10° C to 55° C (14° F to 131° F) |
| Consumption | ≤ 30 W (without HDD and PoE off) |
Auxiliary Interface
| SATA | 2 SATA interfaces |
|---|---|
| USB Interface | Front panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0 |
Intelligent Analytics
| Engine | 1, engine mode is adjustable |
|---|
PoE
| Interface | 16, RJ-45 10/100 Mbps self-adaptive Ethernet interface |
|---|---|
| Power | ≤ 200W |
Perimeter Protection
| Human/Vehicle Analysis | N/A |
|---|
Arvustused
Tooteülevaateid veel ei ole.
