Kirjeldus
Design
Form factorDome
Housing materialMetal
International Protection (IP) codeIP67
Mounting typeCeiling
Product colourWhite
Performance
CertificationCE-LVD: EN60950-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07
Connectivity technologyWired
Day/night modeYes
Infrared (IR) cut-off filterYes
Placement supportedIndoor & outdoor
TypeIP security camera
Wide Dynamic Range (WDR)Yes
Camera
Adjustment shutter speedAuto/Manual
Angle of rotation360 °
Camera shutter speed1/3 s-1/100000 s s
Camera shutter typeElectronic
Lens viewing angle, horizontal102 °
Lens viewing angle, vertical71 °
Minimum illumination0.005 lx
Pan range0 – 360 °
Tilt angle range0 – 78 °
White balanceAuto/Lamp/Manual/Natural/Outdoor
Image sensor
Number of effective pixels (H x V)2592 x 1944 pixels
Number of sensors1
Optical sensor size1/2.7 “
Progressive scanYes
Sensor typeCMOS
Lens system
Fixed focal length2.8 mm
Maximum aperture number1.6
Number of lenses1
Night vision
LED typeIR
Night visionYes
Night vision distance50 m
Number of illumination LEDs2
Video
Back Light Compensation (BLC)Yes
Bit rate32 Kbps-8192 Kbps
Bit rate controlConstant Bit Rate (CBR)/Variable Bit Rate (VBR)
Flip & mirrorYes
Frame rate60 fps
Gain control typeAuto/Manual
Highlight Compensation (HLC)Yes
Maximum resolution2592 x 1944 pixels
Noise reductionYes
Noise reduction technology3D noise reduction
Privacy maskingYes
Region of Interest (ROI) encodingYes
Supported graphics resolutions1280 x 720 (HD 720)/1280 x 960/1920 x 1080 (HD 1080)/2304 x 1296/2560 x 1440/2592 x 1520/352 x 240/352 x 288/640 x 480 (VGA)/704 x 480/704 x 576
Total megapixels5 MP
Video compression formatsH.264
Video streamingYes
Audio
Built-in microphoneYes
Voice codecsAAC/G.711a/G.711Mu/G.723/G.726
Network
BluetoothNo
Ethernet interface typeFast Ethernet
Ethernet LANYes
Networking standardsIEEE 802.3af
Number of users20 user(s)
Quality of Service (QoS) supportYes
Streaming methodMulticast/Unicast
Supported network protocolsIPv4;IPv6;HTTP;HTTPS;TCP;UDP;ARP;RTP;RTSP;RTCP;RTMP;SMTP;FTP;SFTP;DHCP;DNS;DDNS;QoS;UPnP;NTP;Multicast;ICMP;IGMP;NFS;PPPoE;802.1x;SNMP
Wi-FiNo
Storage
Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash)
Internal memory512 MB
ROM capacity128 MB
Ports & interfaces
Ethernet LAN (RJ-45) ports1
Security
Intelligent Video Surveillance (IVS) system featuresCrossing line/Heat map/Intrusion/People counting/Tripwire
Video motion detectionYes
Management features
Web browserYes
Power
DC output voltage12
Power consumption (typical)7.2 W
Power source typeDC,PoE
Operational conditions
Operating relative humidity (H-H)0 – 95 %
Operating temperature (T-T)-30 – 60 °C
Storage temperature (T-T)-30 – 60 °C
System requirements
Mobile operating systems supportedAndroid/iOS
Weight & dimensions
Diameter106 mm
Height93.6 mm
Weight550 g
Packaging data
Package weight710 g
Packaging content
Number of cameras1
Category CodeFNC
Unit Box Height0.13
Unit Box Length0.14
Unit Box Width0.15
ModelIPC-HDW5541TM-ASE-0280B-S3
Units per Shipping Box24
Unit Calculated Volume0.00348 cubm
Unit Calculated Weight0.8 kg
