Kirjeldus
Design
Fog proofYes
Form factorDome
Housing materialMetal
IK codeIK10
International Protection (IP) codeIP67
Mounting typeCeiling/wall
Product colourWhite
Performance
Alarm input/outputYes
Connectivity technologyWired
People counting functionYes
Placement supportedIndoor & outdoor
Plug and PlayYes
TypeIP security camera
Camera
Adjustment shutter speedAuto/Manual
Angle of rotation355 °
Auto flipYes
Camera pan controlYes
Camera shutter speed1/3 – 1/100000 s
Camera shutter typeElectronic
Camera tilt controlYes
Lens viewing angle, horizontal43 °
Lens viewing angle, vertical23 °
Minimum illumination0.002 lx
Pan range0 – 355 °
Tilt angle range0 – 65 °
White balanceAuto/Lamp/Manual/Natural/Outdoor
Image sensor
Number of effective pixels (H x V)2688 x 1520 pixels
Number of sensors1
Optical sensor size1/1.8 “
Progressive scanYes
Sensor typeCMOS
Lens system
Auto focusYes
Fixed focusYes
Focal length range8 – 32 mm
Maximum aperture number1.6
Normal focusing range2.5 – 6 m
Number of lenses1
Night vision
LED typeIR
Night visionYes
Night vision distance80 m
Number of illumination LEDs3
Video
Back Light Compensation (BLC)Yes
Bit rateH.264: 32 Kbps-8192 Kbps, H.265: 19 Kbps- 8192 Kbps
Bit rate controlConstant Bit Rate (CBR)/Variable Bit Rate (VBR)
Digital Wide Dynamic Range (DWDR)Yes
Flip & mirrorYes
Frame rate30 fps
Gain control typeAuto/Manual
Highlight Compensation (HLC)Yes
Maximum resolution2688 x 1520 pixels
Noise reductionYes
Noise reduction technology3D noise reduction
Privacy maskingYes
Region of Interest (ROI) encodingYes
Smart IRYes
Supported graphics resolutions1280 x 720 (HD 720)/1280 x 960/1920 x 1080 (HD 1080)/2304 x 1296/2560 x 1440/2688 x 1520/352 x 240/352 x 288/640 x 480 (VGA)/704 x 576
Supported video modes1080p/720p
Total megapixels5 MP
Video compression formatsH.264/H.264+/H.265/H.265 Pro/H.265 Pro+/H.265+
Video intelligence analyticYes
Video streamingYes
Audio
Audio formats supportedAAC
Audio input channels1.0 channels
Audio output channels1.0 channels
Voice codecsG.711a/G.711alaw/G.723/G.723.1/G.726/G.726-32
Network
BluetoothNo
Ethernet interface typeFast Ethernet
Ethernet LANYes
Networking standardsIEEE 802.1x
Number of users20 user(s)
Quality of Service (QoS) supportYes
Streaming methodMulticast/Unicast
Supported network protocolsIPv4;IPv6;HTTP;HTTPS;TCP;UDP;ARP;RTP;RTSP;RTCP ;RTMP;SMTP;FTP;SFTP;DHCP;DNS;DDNS;QoS;UPnP ;NTP;Multicast;ICMP;IGMP;NFS;PPPoE;SNMP
Wi-FiNo
Storage
Built-in HDDNo
Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size256 GB
Ports & interfaces
DC-in jackYes
Ethernet LAN (RJ-45) ports1
Security
Active tampering alarmYes
MirrorYes
Motion sensorYes
Privacy protectionYes
Video motion detectionYes
Management features
Management softwareSmart PSS, DSS, DMSS
Web browserYes
Web-based managementYes
Power
AC input voltage24 V
DC output voltage12
Power consumption (typical)12.4 W
Power source typeAC,DC,PoE
Operational conditions
Operating relative humidity (H-H)0 – 95 %
Operating temperature (T-T)-30 – 60 °C
Storage temperature (T-T)-30 – 60 °C
System requirements
Mobile operating systems supportedAndroid/iOS
Windows operating systems supportedYes
Weight & dimensions
Depth159 mm
Height117.9 mm
Weight950 g
Packaging content
ManualYes
Number of cameras1
Category CodeFNC
Unit Box Height0.14
Unit Box Length0.15
Unit Box Width0.142
ModelIPC-HDBW5541R-ASE-0280B-S3
Units per Shipping Box1
Unit Calculated Volume0.002982 cubm
Unit Calculated Weight0.75 kg
