Kirjeldus
Design
Form factorTurret
International Protection (IP) codeIP67
Mounting typeCeiling
Product colourWhite
Performance
CertificationCE-LVD: EN 62368-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B
Connectivity technologyWired
Dynamic range120 dB
Placement supportedIndoor & outdoor
TypeIP security camera
Wide Dynamic Range (WDR)Yes
Camera
Adjustment shutter speedAuto/Manual
Angle of rotation360 °
Camera shutter speed1/3 – 1/100000 s
Camera shutter typeElectronic
Lens viewing angle, diagonal114 °
Lens viewing angle, horizontal95 °
Lens viewing angle, vertical52 °
Minimum illumination0.008 lx
Pan range0 – 360 °
Tilt angle range0 – 78 °
Panoramic camera
Number of Privacy masking areas (panoramic camera)4
Image sensor
Number of sensors1
Optical sensor size1/2.9 “
Progressive scanYes
Sensor typeCMOS
Lens system
Closest focusing distance0.9 m
Detect distance63.6 m
Detect distance (tele)85.4 m
Detect distance (wide)63.6 m
Identify distance6.4 m
Identify distance (tele)8.5 m
Identify distance (wide)6.4 m
Maximum aperture number1.6
Normal focusing range0.9 – 1.6 m
Number of lenses1
Observe distance25.4 m
Observe distance (tele)34.2 m
Observe distance (wide)25.4 m
Recognize distance12.7 m
Recognize distance (tele)17.1 m
Recognize distance (wide)12.7 m
Night vision
LED typeIR
Night visionNo
Night vision distance30 m
Number of illumination LEDs2
Video
Back Light Compensation (BLC)Yes
Bit rateH.264: 32 kbps-6144 kbps; H.265: 12 kbps-6144 kbps
Bit rate controlConstant Bit Rate (CBR)/Variable Bit Rate (VBR)
Frame rate30 fps
Gain control typeAuto/Manual
Highlight Compensation (HLC)Yes
Maximum resolution2688 x 1520 pixels
Noise reductionYes
Noise reduction technology3D noise reduction
Privacy maskingYes
Supported graphics resolutions1280 x 720 (HD 720)/1280 x 960/1920 x 1080 (HD 1080)/2304 x 1296/2520 x 1520/2560 x 1440/640 x 480 (VGA)
Supported video modes1080p
Total megapixels4 MP
Video compression formatsH.264/H.264B/H.264H/H.265/M-JPEG
Video formats supportedH.264/H.264+/H.265/H.265+
Video streamingYes
Audio
Bit rate range12 – 6144 Kbit/s
Built-in microphoneYes
Signal-to-Noise Ratio (SNR)56 dB
Voice codecsG.711a/G.711Mu/G.726/PCM
Network
Ethernet interface typeFast Ethernet
Ethernet LANYes
Number of users6 user(s)
Streaming methodMulticast
Supported network protocolsIPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP
Storage
Built-in HDDNo
Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash)
Internal memory128 MB
Maximum memory card size256 GB
ROM capacity128 MB
Ports & interfaces
DC-in jackYes
Ethernet LAN (RJ-45) ports1
Security
Intelligent Video Surveillance (IVS) system featuresHuman detection/Intrusion/Tripwire/Vehicle detection
MirrorYes
Privacy protectionYes
Video motion detectionYes
Management features
Management softwareDSS; DMSS
Web browserYes
Power
DC output voltage12
Power consumption2.1 mA
Power consumption (max)5.2 W
Power consumption (Power over Ethernet (PoE))2.5 W
Power source typeDC,PoE
Operational conditions
Operating relative humidity (H-H)0 – 95 %
Operating temperature (T-T)-40 – 60 °C
Storage temperature (T-T)-40 – 60 °C
System requirements
Mobile operating systems supportedAndroid/iOS
Weight & dimensions
Depth109.9 mm
Diameter109.9 mm
Height100.9 mm
Weight370 g
Width109.9 mm
Packaging data
Package weight510 g
Packaging content
Number of cameras1
Category CodeFNC
Unit Box Height0.11
Unit Box Length0.12
Unit Box Width0.12
Units per Pallet0
Units per Shipping Box30
Unit Calculated Volume0.00196 cubm
Unit Calculated Weight0.545 kg
