Kirjeldus
Design
Form factorDome
Housing materialMetal
IK codeIK10
International Protection (IP) codeIP67
Mounting typeCeiling/Wall/Pole
Product colourWhite
Performance
Alarm input/outputYes
Built-in lightYes
Connectivity technologyWired
Infrared (IR) cut-off filterYes
Placement supportedOutdoor
TypeIP security camera
Wide Dynamic Range (WDR)Yes
Camera
Angle of rotation360 °
Camera shutter speed1/3 – 1/100000 s
Lens viewing angle, diagonal120 °
Lens viewing angle, horizontal101 °
Lens viewing angle, vertical54 °
Minimum illumination0.0006 lx
Number of Privacy masking areas4
Pan range-30 – 30 °
Tilt angle range0 – 80 °
White balanceAuto/Manual/Natural/Outdoor/Regional custom/Street lamp
Image sensor
Optical sensor size1/2.9 “
Progressive scanYes
Sensor typeCMOS
Lens system
Closest focusing distance1.7 m
Detect distance63.6 m
Fixed focal length2.8 mm
Fixed focusYes
Identify distance6.4 m
Number of lenses1
Observe distance25.4 m
Recognize distance12.7 m
Night vision
LED typeIR/White
Night visionYes
Night vision distance30 m
Number of illumination LEDs4
Video
Back Light Compensation (BLC)Yes
Bit rateH.264: 32 kbps-6144 kbps; H.265: 12 kbps-6144 kbps
Bit rate controlConstant Bit Rate (CBR)/Variable Bit Rate (VBR)
Flip & mirrorYes
Gain control typeAuto/Manual
Highlight Compensation (HLC)Yes
Maximum resolution2688 x 1520 pixels
Noise reductionYes
Noise reduction technology3D noise reduction
Region of Interest (ROI) encodingYes
Supported graphics resolutions1280 x 720 (HD 720)/1280 x 960/1920 x 1080 (HD 1080)/2560 x 1440/2688 x 1520/352 x 240/352 x 288/640 x 480 (VGA)/704 x 480/704 x 576
Total megapixels4 MP
Video compression formatsH.264/H.264B/H.264H/H.265/M-JPEG
Video streamingYes
Audio
Audio input channels1.0 channels
Audio output channels1.0 channels
Built-in microphoneYes
Signal-to-Noise Ratio (SNR)56 dB
Voice codecsG.711a/G.711Mu/G.726/PCM
Network
BluetoothNo
Ethernet LANYes
Number of users6 user(s)
Supported network protocolsIPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP; P2P
Wi-FiNo
Storage
Built-in HDDNo
Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size256 GB
RAM capacity128 MB
ROM capacity128 MB
Ports & interfaces
Ethernet LAN (RJ-45) ports1
Security
Active tampering alarmYes
Alarm input channels1
Alarm output channels1
Intelligent Video Surveillance (IVS) system featuresHuman detection/Intrusion/Tripwire/Vehicle detection
Privacy protectionYes
Video motion detectionYes
Management features
Web-based managementYes
Power
DC output voltage12
Power consumption (max)8.5 W
Power consumption (Power over Ethernet (PoE))3.8 W
Power consumption (typical)2.3 W
Power source typeDC,PoE
Operational conditions
Operating relative humidity (H-H)0 – 95 %
Operating temperature (T-T)-40 – 60 °C
Storage relative humidity (H-H)0 – 95 %
Storage temperature (T-T)-40 – 60 °C
Weight & dimensions
Diameter108.9 mm
Height55 mm
Weight410 g
Packaging data
Package weight550 g
Packaging content
Number of cameras1
Category CodeFNC
Unit Box Height0.085
Unit Box Length0.14
Unit Box Width0.135
ModelIPC-HDBW2449F-AS-IL-0280B
Units per Shipping Box1
Unit Calculated Volume0.001607 cubm
Unit Calculated Weight0.54 kg
