Kirjeldus
Design
Form factorBullet
International Protection (IP) codeIP67
Mounting typeCeiling/Wall/Pole
Product colourBlack/White
Performance
Auto pan modeYes
CertificationCE-LVD: EN60950-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B
Connectivity technologyWired
Day/night modeYes
Maximum operating distance50 m
Placement supportedOutdoor
TypeIP security camera
Wide Dynamic Range (WDR)Yes
Camera
Adjustment shutter speedAuto/Manual
Angle of rotation360 °
Camera pan controlYes
Camera shutter speed1/3 s-1/100,000 s
Camera tilt controlYes
Minimum illumination0.0005 lx
Pan range0 – 360 °
Tilt angle range0 – 90 °
White balanceAuto
Image sensor
Optical sensor size1/2.8 “
Sensor typeCMOS
Lens system
Closest focusing distance1.2 m
Detect distance (tele)131 m
Detect distance (wide)48 m
Focal length range2.8 – 12 mm
FocusMotorized/Manual
Identify distance13 m
Identify distance (tele)13 m
Identify distance (wide)5 m
Normal focusing range1.2 m
Number of lenses1
Observe distance (tele)52 m
Observe distance (wide)19 m
Recognize distance (tele)26 m
Recognize distance (wide)10 m
Night vision
LED typeIR
Night visionYes
Night vision distance50 m
Number of illumination LEDs2
Video
Back Light Compensation (BLC)Yes
Bit rateH.264: 32 kbps-6144 kbps, H.265: 12 kbps-6144 kbps
Bit rate controlConstant Bit Rate (CBR),Variable Bit Rate (VBR)
Digital Wide Dynamic Range (DWDR)Yes
Frame rate30 fps
Gain control typeAuto/Manual
Highlight Compensation (HLC)Yes
Maximum resolution1920 x 1080 pixels
Noise reductionYes
Noise reduction technology3D noise reduction
Privacy maskingYes
Region of Interest (ROI) encodingYes
Smart IRYes
Supported graphics resolutions1280 x 720 (HD 720)/1280 x 960/1920 x 1080 (HD 1080)/352 x 240/352 x 288/640 x 480 (VGA)/704 x 480/704 x 576
Supported video modes1080p/720p
Total megapixels2 MP
Video compression formatsH.264/H.264+/H.265/H.265+
Video streamingYes
Network
BluetoothNo
Ethernet interface typeFast Ethernet
Ethernet LANYes
Number of users6 user(s)
Supported network protocolsIPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; SMTP; FTP; DHCP; DNS; NTP; Multicast; DDNS
Wi-FiNo
Storage
Built-in HDDNo
Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash)
Internal memory128 MB
Maximum memory card size256 GB
ROM capacity16 MB
Ports & interfaces
Ethernet LAN (RJ-45) ports1
Power
DC output voltage12
Power consumption (max)4.3 W
Power consumption (Power over Ethernet (PoE))5.5 W
Power consumption (typical)1.8 W
Power source typeDC,PoE
Operational conditions
Operating relative humidity (H-H)0 – 95 %
Operating temperature (T-T)-30 – 60 °C
Weight & dimensions
Diameter90.4 mm
Height244.1 mm
Weight860 g
Packaging data
Package weight1120 g
Packaging content
Number of cameras1
Category CodeFNC
Unit Box Height0.16
Unit Box Length0.31
Unit Box Width0.145
Units per Shipping Box1
Unit Calculated Volume0.007192 cubm
Unit Calculated Weight1.08 kg
