Base Attributes
| Manufacturer Code | PTZ-N2C400M-DE(2.8mm)(B) |
|---|---|
| Net Weight | 0.595 |
| Gross Weight | 1.026 |
Key Parameter
| Resolutsioon | 4 MP |
|---|---|
| Illumination Level | Powered by Darkfighter |
| Wireless Network | N/A |
| IR Distance | 21-50m |
Camera
| Image Sensor | 1/3″ Progressive Scan CMOS |
|---|---|
| Min. Illumination | Color: 0.01 Lux @(F1.2，AGC ON), B/W: 0 Lux with light |
Lens
| FOV | 2.8 mm, horizontal FOV 104.9°, vertical FOV 58.3°, diagonal FOV 123.3° 4 mm, horizontal FOV 81.3°, vertical FOV 43.7°, diagonal FOV 96.9° |
|---|
Illuminator
| Supplement Light Type | IR & White Light |
|---|---|
| Supplement Light Range | White Light Distance: up to 30 m IR Distance: up to 30 m |
| Smart Supplement Light | Yes |
PTZ
| Movement Range (Pan) | 0° to 345° |
|---|---|
| Movement Range (Tilt) | 0° to 80° |
Video
| Video Bit Rate | 32 Kbps to 8 Mbps |
|---|---|
| Main Stream | 50 Hz: 20 fps (2560 × 1440, 1920 × 1080, 1280 × 720) 60 Hz: 20 fps (2560 × 1440, 1920 × 1080, 1280 × 720) |
Network
| Protocols | IPv4/IPv6, HTTP, HTTPS, Qos, DNS, DDNS, NTP, RTSP, RTP, TCP/IP, UDP, DHCP, Bonjour |
|---|
Interface
| On-Board Storage | Built-in memory card slot, support microSD/SDHC/SDXC card, up to 512 GB |
|---|---|
| Built-in Microphone | 1 built-in microphone |
| Built-in Speaker | 1 built-in speaker |
Event
| Basic Event | Motion detection (support alarm triggering by specified target type (human)), video tampering alarm, exception |
|---|
General
| General Function | Mirror, password protection, watermark |
|---|---|
| Operating Condition | -10 °C to 40 °C (-14 °F to 104 °F). Humidity 90% or less (non-condensing) |
| Power Supply | DC12V&PoE |
Approval
| Protection | IP66 |
|---|
