Kirjeldus
Base Attributes
| Brand | Hikvision |
|---|---|
| Manufacturer Code | DS-2SF8C848MXG1-ELWY/26(F0) |
| Net Weight | 11.601 |
| Gross Weight | 17.2 |
Key Parameter
| Resolutsioon | 8 MP, 6 MP |
|---|---|
| Optical Zoom | 31-50X |
| Low-Light Imaging | Darkfighter, ColorVu |
| Illumination Distance | >300m |
| Wireless Network | N/A |
| Supplemental Light | IR Light, White Light |
Camera
| Image Sensor | [Bullet channel] 1/2.5″ Progressive Scan CMOS, [PTZ channel] 1/1.2″ Progressive Scan CMOS |
|---|---|
| Min. Illumination | [Bullet channel] Color: 0.0005 Lux @ (F1.0, AGC ON), B/W: 0.0001 Lux @ (F1.0, AGC ON), 0 Lux with light, [PTZ channel] Color: 0.0005 Lux @ (F1.6, AGC ON), B/W: 0.0001 Lux @ (F1.6, AGC ON), 0 lux with IR |
| Day & Night | [Panoramic channel] Color, [PTZ channel] IR cut filter |
| Zoom | [PTZ channel] 48 × optical, 16 × digital |
Lens
| FOV | [Panoramic channel] horizontal field of view: 190° ± 5°°, vertical field of view: 80° ± 5°, [PTZ channel] horizontal field of view: 58.5° to 3.1°, vertical field of view: 34° to 1.7°, diagonal field of view: 65.8° to 3.5° |
|---|
Illuminator
| Supplement Light Range | [Bullet channel] white light: up to 30 m, [PTZ channel] Laser: up to 500 m |
|---|---|
| Smart Supplement Light | Yes |
PTZ
| Movement Range (Pan) | 360° endless |
|---|---|
| Movement Range (Tilt) | [Panoramic channel] 12° to 24°, [PTZ channel] -20° to 90° |
| Patrol Scan | 8 patrols, up to 32 presets for each patrol |
| Pattern Scan | 4 pattern scans, record time over 10 minutes for each scan |
| Scheduled Task | Preset,pattern scan,patrol scan,auto scan,tilt scan,random scan,frame scan,panorama scan,dome reboot,dome adjust,aux output |
Video
| Video Bit Rate | 32 Kbps to 16 Mbps |
|---|---|
| Main Stream | [Panoramic channel] 50 Hz: 25 fps (3680 × 1656，3632 × 1632), 60 Hz: 30 fps (3680 × 1656，3632 × 1632) [PTZ channel] 50 Hz: 50 fps (3840 × 2160, 2560 × 1440), 100 fps (1920 × 1080, 1280 × 960, 1280 × 720), 60 Hz: 60 fps (3840 × 2160, 2560 × 1440), 120 fps (1920 × 1080, 1280 × 960, 1280 × 720) *High frame rate is supported under monitoring mode only. |
Network
| Simultaneous Live View | Up to 20 channels |
|---|---|
| Protocols | IPv4/IPv6,HTTP,HTTPS,802.1X,QoS,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP/IP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour,FTP |
| User/Host | Up to 32 users. 3 user levels: administrator, operator, and user |
| Client | iVMS-4200,HikCentral Pro,Hik-Connect |
| Security | Password protection,complicated password,IP address filter,HTTPS encryption,802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5),host authentication (MAC address),watermark, TPM 2.0 (FIPS 140-2 level 2) |
| Day/Night Switch | Day,night,auto,schedule |
|---|---|
| SNR | ≥ 52 dB |
| Image Stabilization | OIS |
| Defog | Optical defog |
Interface
| Audio | 1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%, 1 output (line out), line level, output impedance: 600 Ω |
|---|---|
| On-Board Storage | Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 1 TB . |
| Built-in Speaker | 1 built-in speaker |
| Alarm | 7 input(s), 2 output(s) |
Event
| Basic Event | [PTZ channel & panoramic channel] alarm input and output, exception,[PTZ channel] video tampering alarm |
|---|---|
| Smart Event | Line crossing detection,intrusion detection,region entrance detection,region exiting detection,unattended baggage detection,object removal detection,loitering detection,people gathering detection,fast moving detection,parking detection |
Deep Learning Function
| Face Capture | Detects up to 30 faces simultaneously, Uploads face with background and closed-up face pictures |
|---|---|
| Face Comparison | Up to 10 face libraries. 30000 faces for each library. 150000 faces in total, Recognizes face identity via face modeling, grading and comparing to those in face library, Supports face library encryption |
| Multi-target-type Detection | Supports simultaneous detection and capture of human body, face and vehicle, Gets 7 face features, 14 human body features and 8 vehicle features |
| Perimeter Protection | Line crossing detection, region entrance detection, intrusion detection, region exiting detection |
General
| Demist | Yes |
|---|---|
| General Function | mirror,password protection |
| Operating Condition | -40 °C to 70 °C (-40 °F to 158 °F). Humidity 95% or less (non-condensing),For speaker: -30 °C to 55°C (-22°F to 131°F) |
| Power Supply | Hi-PoE, 36 VDC |
| Wiper | Yes |
| Dimension | Ø290 mm × 453.2 mm (Ø11.42″ × 17.84″) |
Approval
| Anti-Corrosion Protection | NEMA 4X (NEMA 250-2018) |
|---|---|
| Protection | IP67 (IEC 60529-2013),TVS 6000 V lightning protection, surge protection and voltage transient protection,IK10 (IEC 62262:2002, excluding glass window) |
| Safety | CB (IEC 62368-1: 2014 + A11),CE-LVD (EN 62368-1: 2014/A11: 2017) |
