Kirjeldus
Base Attributes
| Brand | Hikvision |
|---|---|
| Manufacturer Code | DS-2SE4C425MWG-E/26(F0) |
| Net Weight | 2.85 |
| Gross Weight | 5.01 |
Key Parameter
| Resolutsioon | 6 MP, 4 MP |
|---|---|
| Optical Zoom | 21-30X |
| Low-Light Imaging | ColorVu, Powered by Darkfighter |
| Illumination Distance | 51-100m |
| Wireless Network | N/A |
Camera
| Image Sensor | [Bullet channel]: 1/2.5″ Progressive Scan CMOS; [PTZ channel]: 1/2.8″ progressive scan CMOS |
|---|---|
| Min. Illumination | [Bullet channel]: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light; [PTZ channel]: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with IR |
| Day & Night | ICR |
| Zoom | [PTZ channel] 25 × optical, 16 × digital |
Lens
| FOV | [Bullet channel]: Horizontal field of view: 180±10°, Vertical field of view: 80±5°; [PTZ channel]: Horizontal field of view: 55° to 2.4° (wide-tele), Vertical field of view: 33° to 1.4° (wide-tele), Diagonal field of view: 61.5° to 2.8° (wide-tele) |
|---|
Illuminator
| Supplement Light Type | [PTZ channel]: IR; [Bullet channel]: White Light |
|---|---|
| Supplement Light Range | [PTZ channel]: up to 100 m; [Bullet channel]: up to 30 m |
| Smart Supplement Light | Yes |
PTZ
| Movement Range (Pan) | 360° |
|---|---|
| Movement Range (Tilt) | -15° to 90° (auto flip) |
| Patrol Scan | 8 patrols, up to 32 presets for each patrol |
| Pattern Scan | 4 pattern scans |
| Scheduled Task | preset||pattern scan||patrol scan||auto scan||tilt scan||random scan||frame scan||panorama scan||dome reboot||dome adjust||aux output |
Video
| Video Bit Rate | 32 kbps to 16384 kbps |
|---|---|
| Main Stream | [Bullet channel] 50 Hz：25 fps（3632 × 1632，3680 × 1656） 60 Hz：30 fps（3632 × 1632，3680 × 1656） [PTZ channel] 50 Hz：25 fps（2560 × 1440，1920 × 1080，1280 × 960，1280 × 720） 60 Hz：30 fps（2560 × 1440，1920 × 1080，1280 × 960，1280 × 720） |
Network
| Simultaneous Live View | 20 |
|---|---|
| Protocols | IPv4/IPv6||HTTP||HTTPS||802.1x||Qos||FTP||SMTP||UPnP||SNMP||DNS||DDNS||NTP||RTSP||RTCP||RTP||TCP/IP||UDP||IGMP||ICMP||DHCP||PPPoE||Bonjour||WebSocket||WebSockets |
| User/Host | 32 |
| Client | iVMS-4200||Hik-Connect |
| Security | Authenticated username and password||MAC address binding||HTTPS encryption||802.1X authenticated access||IP address filter |
| Day/Night Switch | day, night, auto, scheduled-switch |
|---|---|
| SNR | ≥ 52 dB |
| Image Stabilization | EIS |
| Defog | Digital defog |
Interface
| Audio | 1 audio input, 2.0 to 2.4Vp-p, 1k Ohm±10%, 1 audio output, line level, impedance: 600 Ω |
|---|---|
| On-Board Storage | Built-in memory card slot, support Micro SD/Micro SDHC/Micro SDXC, up to 256 GB |
| Alarm | 1 alarm input, 1 alarm output |
Event
| Basic Event | [PTZ channel] motion detection, video tampering alarm,[PTZ channel & bullet channel] alarm input and output, exception (IP address conflict, HDD full, illegal login, HDD error, network disconnected, Abnormal Reboot) |
|---|---|
| Smart Event | [PTZ channel & bullet channel] audio exception detection,[PTZ channel] line crossing detection, intrusion detection, region entrance detection, region exiting detection,[Bullet channel] line crossing detection, intrusion detection, region entrance detection, region exiting detection |
Deep Learning Function
| Face Capture | Detects up to 5 faces simultaneously, Supports detecting, tracking, capturing, grading, selecting of face in motion, and outputs the best face picture |
|---|---|
| Regional People Counting | Yes |
General
| Demist | Demist by heating the glass |
|---|---|
| General Function | mirror,watermark,password protection |
| Operating Condition | -30℃ to 65℃ (-22°F to 149°F) ||humidity lower than 90%RH |
| Power Supply | PoE+, 12 VDC |
| Dimension | Ø 166 mm × 375 mm (Ø 6.5″ × 14.7″) |
Approval
| Protection | IP66 Standard, 6000 V Lightning Protection, Surge Protection and Voltage Transient Protection |
|---|
