Kirjeldus
Base Attributes
| Brand | Hikvision |
|---|---|
| Manufacturer Code | DS-7616NXI-K2/16P(D) |
| Net Weight | 2.51 |
| Gross Weight | 3.7 |
Key Parameter
| Wireless Network | N/A |
|---|---|
| AI | Face Capture, Perimeter Protection, Face Recognition, Yes |
| IP Channel Number | 16-ch |
| HDD Interface | 2 |
| PoE Interface | 16-ch |
| Decoding Capability | 16-ch@1080p |
| External Interface | HDMI, VGA |
| RAID | No |
| Chassis | 1U |
Video and Audio
| Incoming Bandwidth | 160 Mbps |
|---|---|
| Outgoing Bandwidth | 160 Mbps |
| Video Output Mode | HDMI/VGA independent output |
Decoding
| Decoding Format | H.265/H.265+/H.264+/H.264 |
|---|
Network
| Network Interface | 1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
|---|---|
| Remote Connection | 128 |
General
| Power Supply | 100 to 240 VAC, 50 to 60 Hz |
|---|---|
| Working Humidity | 10% to 90% |
| Working Temperature | -10 °C to 55 °C (14 °F to 131 °F) |
| Consumption | ≤ 15 W (without HDD and PoE off) |
Auxiliary Interface
| SATA | 2 SATA interfaces |
|---|---|
| USB Interface | Front panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0 |
PoE
| Interface | 16, RJ-45 10/100 Mbps self-adaptive Ethernet interface |
|---|---|
| Power | ≤ 200 W |
