Base Attributes
| Manufacturer Code | DS-7732NI-M4 |
|---|---|
| Net Weight | 4.06 |
| Gross Weight | 6.3 |
Key Parameter
| Wireless Network | N/A |
|---|---|
| AI | N/A |
| IP Channel Number | 32-ch |
| HDD Interface | 4 |
| PoE Interface | N/A |
| Decoding Capability | 32-ch@1080p |
| External Interface | HDMI, VGA |
| RAID | Ei |
| Chassis | 1.5U |
Video and Audio
| Incoming Bandwidth | 320 Mbps |
|---|---|
| Outgoing Bandwidth | 400 Mbps |
| Video Output Mode | HDMI1/VGA simultaneous output, HDMI2/VGA independent output |
Decoding
| Decoding Format | H.265+/H.265/H.264+/H.264 |
|---|
Network
| Network Interface | 2 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interfaces |
|---|---|
| Remote Connection | 128 |
General
| Kaubamärgid | HIKVISION |
|---|---|
| Power Supply | 100 to 240 VAC, 50 to 60 Hz |
| Working Humidity | 10% to 90% |
| Working Temperature | -10 °C to 55 °C (14 °F to 131 °F) |
| Consumption | ≤ 15 W (without HDD ) |
Auxiliary Interface
| eSATA | 1 eSATA interface |
|---|---|
| SATA | 4 SATA interfaces |
| USB Interface | Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0 |
