Kirjeldus
Design
Form factorTurret
Housing materialMetal/Plastic
International Protection (IP) codeIP67
Mounting typeCeiling/wall
Product colourWhite
Performance
Connectivity technologyWired
Day/night modeYes
Dynamic range120 dB
Infrared (IR) cut-off filterYes
Placement supportedIndoor & outdoor
TypeIP security camera
Wide Dynamic Range (WDR)Yes
Camera
Camera pan controlYes
Camera shutter speed1/3 – 1/10000 s
Camera tilt controlYes
Lens viewing angle, diagonal98.7 °
Lens viewing angle, horizontal80.4 °
Lens viewing angle, vertical41.8 °
Minimum illumination0.005 lx
Number of Privacy masking areas4
Pan range0 – 360 °
Tilt angle range0 – 85 °
Image sensor
Optical sensor size1/2.7 “
Progressive scanYes
Sensor typeCMOS
Lens system
Detect distance80 m
Fixed focal length4 mm
Focal length range4 mm
Identify distance8 m
Lens diameter4 mm
Maximum aperture number1.6
Minimum aperture number1.6
Number of lenses1
Observe distance33 m
Recognize distance16 m
Night vision
Infra-red wavelength850 nm
LED typeIR
Night visionYes
Night vision distance30 m
Number of illumination LEDs4
Video
Bit rate6 Mbps
Bit rate controlConstant Bit Rate (CBR),Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Frame rate60 fps
Maximum resolution2688 x 1520 pixels
Noise reductionYes
Noise reduction technology3D noise reduction
Region of Interest (ROI) encodingYes
Smart IRYes
Supported graphics resolutions1280 x 720 (HD 720)/1920 x 1080 (HD 1080)/2048 x 1280/2304 x 1296/2550 x 1440/2688 x 1520
Total megapixels4 MP
Video compression formatsH.264/H.264+/H.265/H.265+
Audio
Bit rate range64 – 64 Kbit/s
Built-in microphoneYes
Built-in speaker(s)Yes
Sample rate8 kHz
Signal-to-Noise Ratio (SNR)52 dB
Network
Ethernet interface typeFast Ethernet
Ethernet LANYes
Supported network protocolsTCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
Ports & interfaces
Ethernet LAN (RJ-45) ports1
Security
Digest authenticationYes
IP address filteringYes
Password protectionYes
Privacy protectionYes
Power
Power consumption (max)10.1 W
Power source typeDC
Operational conditions
Operating relative humidity (H-H)0 – 95 %
Operating temperature (T-T)-30 – 60 °C
Storage relative humidity (H-H)0 – 95 %
Storage temperature (T-T)-40 – 60 °C
Weight & dimensions
Depth111 mm
Height83.7 mm
Weight480 g
Width111 mm
Packaging content
Number of cameras1
Category CodeFNC
Unit Box Height0.12
Unit Box Length0.16
Unit Box Width0.16
ModelVIGI C455(4MM)
Units per Shipping Box1
Unit Calculated Volume0.003072 cubm
Unit Calculated Weight0.735 kg
