Kirjeldus
Design
Form factorTurret
Housing materialPlastic
International Protection (IP) codeIP66
Mounting typeCeiling/wall
Product colourBlack/White
Performance
CertificationRCM, BSMI, VCCI, NTRA, KC
Connectivity technologyWired
Placement supportedIndoor & outdoor
TypeIP security camera
Camera
Camera pan controlYes
Camera tilt controlYes
Lens viewing angle, diagonal93 °
Lens viewing angle, horizontal79 °
Lens viewing angle, vertical43 °
Pan range0 – 350 °
Tilt angle range0 – 120 °
Image sensor
Optical sensor size1/3 “
Sensor typeCMOS
Lens system
Lens diameter4 mm
Number of lenses1
Zoom capabilityYes
Night vision
LED typeIR
Night visionYes
Night vision distance30 m
Video
Bit rate256 Kbps – 4 Mbps
Digital Wide Dynamic Range (DWDR)Yes
Frame rate30 fps
Image quality adjustmentBrightness/Contrast/Mirror/Saturation/Sharpness
Maximum resolution2560 x 1440 pixels
Noise reductionYes
Noise reduction technology3D noise reduction
Privacy maskingYes
Supported graphics resolutions1920 x 1080 (HD 1080)/2048 x 1280/2304 x 1296/2560 x 1440/320 x 240/352 x 288/640 x 480 (VGA)
Total megapixels4 MP
Video compression formatsH.264/H.264+/H.265/H.265+
Video streamingYes
Audio
Built-in microphoneYes
Built-in speaker(s)Yes
Network
BluetoothNo
Ethernet interface typeFast Ethernet
Ethernet LANYes
Live viewYes
Number of simultaneous live view channels3 channels
Supported network protocolsTCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
Wi-FiNo
Storage
Built-in HDDNo
Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size256 GB
Ports & interfaces
Ethernet LAN (RJ-45) ports1
Security
Digest authenticationYes
HTTPS encryptionYes
Intelligent Video Surveillance (IVS) system featuresHuman detection
IP address filteringYes
MirrorYes
Password protectionYes
Management features
Behavior analysisIntrusion detection,Line crossing detection
Reset buttonYes
Power
DC output voltage12
Power consumption (Power over Ethernet (PoE))14 W
Power source typePoE
Operational conditions
Operating temperature (T-T)-30 – 60 °C
Weight & dimensions
Depth172 mm
Height198 mm
Width120 mm
Sustainability
Compliance certificatesCE/RoHS
Packaging data
Package depth213 mm
Package height243 mm
Package weight950 g
Package width163 mm
Packaging content
Mounting kitYes
Number of cameras1
Category CodeFNC
Unit Box Height0.215
Unit Box Length0.245
Unit Box Width0.165
ModelVIGI C540
Units per Shipping Box8
Unit Calculated Volume0.01004 cubm
Unit Calculated Weight1.18 kg
