Kirjeldus
Design
Form factorBullet
Housing materialMetal
International Protection (IP) codeIP67
Mounting typeWall
Product colourWhite
Performance
Built-in lightYes
CertificationCE, NTRA, VCCI, KC, BSMI, FCC, IC
Connectivity technologyWired
Day/night modeYes
Dynamic range120 dB
Infrared (IR) cut-off filterYes
Placement supportedOutdoor
TypeIP security camera
Wide Dynamic Range (WDR)Yes
Camera
Angle of rotation360 °
Camera shutter speed1/3 to 1/10000 s
Lens viewing angle, diagonal67.2 °
Lens viewing angle, horizontal57.3 °
Lens viewing angle, vertical31.3 °
Minimum illumination0.005 lx
Number of Privacy masking areas4
Pan range0 – 360 °
Tilt angle range0 – 90 °
Image sensor
Optical sensor size1/2.7 “
Progressive scanYes
Sensor typeCMOS
Lens system
Detect distance120 m
Fixed focal length6 mm
Identify distance12 m
Maximum aperture number1.6
Number of lenses1
Observe distance50 m
Recognize distance24 m
Night vision
Infra-red wavelength850 nm
LED typeIR/White
Night visionYes
Night vision distance30 m
Number of illumination LEDs4
Video
Back Light Compensation (BLC)Yes
Bit rate6 Mbps
Bit rate controlConstant Bit Rate (CBR),Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Frame rate30 fps
Highlight Compensation (HLC)Yes
Image quality adjustmentBrightness/Contrast/Mirror/Saturation/Sharpness
Maximum resolution2880 x 1620 pixels
Noise reductionYes
Noise reduction technology3D noise reduction
Privacy maskingYes
Region of Interest (ROI) encodingYes
Smart IRYes
Supported graphics resolutions1280 x 720 (HD 720)/1920 x 1080 (HD 1080)/2048 x 1280/2304 x 1296/2688 x 1520/2880 x 1620
Total megapixels5 MP
Video compression formatsH.264/H.264+/H.265/H.265+
Audio
Audio formats supportedG.711
Audio system2-way
Built-in microphoneYes
Built-in speaker(s)Yes
Sample rate8 kHz
Signal-to-Noise Ratio (SNR)52 dB
Network
BluetoothNo
Ethernet interface typeFast Ethernet
Ethernet LANYes
Supported network protocolsTCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
Wi-FiNo
Storage
Built-in HDDNo
Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size512 GB
Ports & interfaces
DC-in jackYes
Ethernet LAN (RJ-45) ports1
Security
Digest authenticationYes
IP address filteringYes
Password protectionYes
Privacy protectionYes
Management features
Web browserYes
Power
DC output voltage12
Power consumption (max)10.7 W
Power source typeDC,PoE
Operational conditions
Operating relative humidity (H-H)0 – 95 %
Operating temperature (T-T)-30 – 60 °C
Storage relative humidity (H-H)0 – 95 %
Storage temperature (T-T)-40 – 60 °C
Weight & dimensions
Height74 mm
Length74 mm
Weight525 g
Width184 mm
Packaging content
Number of cameras1
Category CodeFNC
Unit Box Height0.105
Unit Box Length0.22
Unit Box Width0.13
ModelVIGI C355(6MM)
Units per Shipping Box1
Unit Calculated Volume0.003003 cubm
Unit Calculated Weight0.79 kg
