Kirjeldus
Design
Housing materialPlastic
International Protection (IP) codeIP66
Mounting typeCeiling
Product colourBlack/White
Performance
CertificationCE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC
Connectivity technologyWired
Placement supportedIndoor & outdoor
PTZ controlYes
TypeIP security camera
Camera
Camera pan controlYes
Camera tilt controlYes
Lens viewing angle, diagonal100 °
Lens viewing angle, horizontal84 °
Lens viewing angle, vertical46 °
Pan range0 – 332 °
Pan speed55 °/sec
Tilt angle range0 – 120 °
Tilt speed40 °/sec
Image sensor
Number of sensors1
Optical sensor size1/3 “
Sensor typeCMOS
Lens system
Digital zoom3 x
Focal length range4 – 12 mm
Maximum aperture number1.6
Number of lenses1
Zoom capabilityYes
Night vision
Infra-red wavelength850 nm
LED typeIR
Night visionYes
Night vision distance30 m
Number of illumination LEDs1
Video
Bit rate256 Kbps – 4 Mbps
Bit rate controlConstant Bit Rate (CBR),Variable Bit Rate (VBR)
Frame rate30 fps
Maximum resolution2560 x 1440 pixels
Supported graphics resolutions1280 x 720 (HD 720)/1920 x 1080 (HD 1080)/2048 x 1280/2304 x 1296/2560 x 1440
Supported video modes1080p/1440p/720p
Total megapixels4 MP
Video formats supportedH.264/H.264+/H.265/H.265+
Video recordingYes
Network
BluetoothNo
Ethernet interface typeFast Ethernet
Ethernet LANYes
Wi-FiNo
Storage
Built-in HDDNo
Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size256 GB
Ports & interfaces
Ethernet LAN (RJ-45) ports1
Power
DC output voltage12
Power consumption (max)14 W
Power consumption (typical)2.9 W
Power source typePoE
Operational conditions
Operating relative humidity (H-H)5 – 95 %
Operating temperature (T-T)-30 – 60 °C
Storage relative humidity (H-H)5 – 95 %
Storage temperature (T-T)-40 – 60 °C
Weight & dimensions
Depth139 mm
Height107 mm
Weight430 g
Width136 mm
Packaging data
Package typeBox
Package weight660 g
Packaging content
ManualYes
Number of cameras1
Category CodeFNC
Unit Box Height0.16
Unit Box Length0.19
Unit Box Width0.15
ModelVIGI C540V
Units per Shipping Box1
Unit Calculated Volume0.00456 cubm
Unit Calculated Weight0.7 kg
