Kirjeldus
Base Attributes
| Brand | Hikvision |
|---|---|
| Manufacturer Code | DS-2DF6A436X-AEL(T5) |
| Net Weight | 5.76 |
| Gross Weight | 8.63 |
Key Parameter
| Resolutsioon | 4 MP |
|---|---|
| Optical Zoom | 31-50X |
| Low-Light Imaging | Darkfighter |
| Illumination Distance | N/A |
| Wireless Network | N/A |
Camera
| Image Sensor | 1/1.8″ progressive scan CMOS |
|---|---|
| Min. Illumination | Color: 0.001 Lux @ (F1.2, AGC ON), B/W: 0.0005 Lux @(F1.2, AGC ON), 0 Lux with IR |
| Day & Night | IR cut filter |
| Zoom | 36x optical, 16x digital |
Lens
| FOV | Horizontal field of view: 56.6° to 1.7° (wide-tele), Vertical field of view: 33.7° to 0.9° (wide-tele), Diagonal field of view: 63.4° to 1.9° (wide-tele) |
|---|
PTZ
| Movement Range (Pan) | 360° |
|---|---|
| Movement Range (Tilt) | -20° to 90° (auto flip) |
| Patrol Scan | 8 patrols, up to 32 presets for each patrol |
| Pattern Scan | 4 pattern scans, record time over 10 minutes for each scan |
| Scheduled Task | Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux output |
Video
| Video Bit Rate | 32 Kbps to 16384 Kbps |
|---|---|
| Main Stream | 50 Hz: 25 fps (2560×1440, 1920×1080, 1280×960, 1280×720) 60 Hz: 30fps (2560×1440, 1920×1080, 1280×960, 1280×720) |
Network
| Simultaneous Live View | Up to 20 channels |
|---|---|
| Protocols | IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, DHCP, PPPoE, UDP, IGMP, ICMP, Bonjour |
| User/Host | Up to 32 users. 3 levels: Administrator, Operator and User |
| Client | iVMS-4200, Hik-Connect, HikCentral |
| Security | User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering |
| Day/Night Switch | Day, night, auto, scheduled-switch |
|---|---|
| SNR | ≥ 52 dB |
| Image Stabilization | EIS (Built-in gyroscope to improve EIS performance) |
| Defog | Optical defog |
Interface
| Audio | 1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%; 1 output (line out), line level, output impedance: 600 Ω |
|---|---|
| On-Board Storage | Built-in memory card slot, support MicroSD/MicroSDHC/MicroSDXC, up to 256 GB; NAS (NFS, SMB/ CIFS), ANR |
| Alarm | 7 alarm inputs, 2 alarm outputs |
Event
| Basic Event | Motion detection, video tampering alarm, alarm input and output, exception |
|---|---|
| Smart Event | Intrusion detection, line crossing detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, vandal-proof alarm, audio exception detection |
| Smart Tracking | Manual tracking, auto-tracking |
Deep Learning Function
| Face Capture | Support detecting up to 30 faces at the same time. Support detecting, tracking, capturing, grading, selecting of face in motion, and output the best face picture |
|---|---|
| Perimeter Protection | Line crossing, intrusion, region entrance, region exiting Support alarm triggering by specified target types (human and vehicle) |
General
| General Function | Mirror, password protection, watermark, IP address filter |
|---|---|
| Operating Condition | Temperature: -40°C to 70°C (-40°F to 158°F), Humidity: ≤ 95% |
| Power Supply | Hi-PoE, 24 VAC |
| Dimension | ⌀ 231.1 mm × 355.6 mm (⌀ 9.10″ × 14″) |
Approval
| Protection | Lightning Protection, Surge Protection and Voltage Transient Protection, ±6 kV Line to Gnd, ±3kV Line to Line, IK10 (IEC 62262:2002), IP67 (IEC 60529-2013) |
|---|---|
| Safety | UL (UL 62368-1) CB (IEC 62368-1:2014+A11); CE-LVD (EN 62368-1:2014+A11:2017), BIS (IS 13252(Part 1):2010/ IEC 60950-1: 2005); LOA (IEC/EN 60950-1) |
