Kirjeldus
Base Attributes
| Brand | Hikvision |
|---|---|
| Manufacturer Code | DS-2CV2041G2-IDW(4mm)(W) |
| Net Weight | 0.6 |
| Gross Weight | 0.643 |
Key Parameter
| Case type | Bullet |
|---|---|
| Resolutsioon | 4 MP |
| Lens Type | Fixed Lens |
| Low-Light Imaging | Normal |
| Illumination Distance | 21-50m |
| Wireless Network | Wi-Fi |
| Storage Type | SD Card |
| AI | N/A |
| Local Output | N/A |
Camera
| Image Sensor | 1/3″ Progressive Scan CMOS |
|---|---|
| Min. Illumination | Color: 0.5 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR |
| Day & Night | IR cut filter |
| Angle Adjustment | Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360° |
Camera Module
| WDR | 120 dB |
|---|
Lens
| Focal Length & FOV | 2.8 mm, horizontal FOV 97°, vertical FOV 53°, diagonal FOV 117° 4 mm, horizontal FOV 82°, vertical FOV 44°, diagonal FOV 100° |
|---|---|
| Iris Type | Fixed |
| Depth of Field | 2.8 mm: 1 m to ∞ 4 mm: 1.5 m to ∞ |
Illuminator
| Supplement Light Type | IR |
|---|---|
| Supplement Light Range | Up to 30 m |
| Smart Supplement Light | Yes |
Video
| Video Bit Rate | 256 Kbps to 4 Mbps |
|---|---|
| Main Stream | 50 Hz: 20 fps (2560 × 1440), 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 20 fps (2560 × 1440), 30 fps (1920 × 1080, 1280 × 720) |
| Bit Rate Control | CBR,VBR |
Network
| Simultaneous Live View | Up to 4 channels |
|---|---|
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, DHCP, DNS, RTP, RTSP, RTCP, NTP, IGMP, QoS, Bonjour |
| User/Host | Only one user: administrator |
| Client | Hik-Connect, iVMS-4200 |
| Security | Password protection, HTTPS encryption, Security Audit Log, basic and digest authentication for HTTP/HTTPS |
Wi-Fi
| Frequency Range | 2.412 GHz to 2.472 GHz |
|---|---|
| Modulation | 802.11n: BPSK, QPSK, 16QAM, and 64QAM,802.11b: DBPSK and DQPSK, CCK,802.11g: BPSK, QPSK, 16QAM, and 64QAM |
| Wireless Range | Up to 120 m (The performance varies based on actual environment) |
| Day/Night Switch | Auto, Schedule, Day, Night |
|---|---|
| SNR | ≥ 52 dB |
Interface
| On-Board Storage | Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB |
|---|---|
| Built-in Microphone | Yes |
| Built-in Speaker | YES |
Event
| Basic Event | Motion detection (support alarm triggering by specified target types (human and vehicle)), exception |
|---|
General
| General Function | Heartbeat, mirror, password protection |
|---|---|
| Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Power Supply | 12 VDC |
| Startup and Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Dimension | 175.6 mm × 73 mm × 89.1 mm (6.9″ × 2.9″ × 3.5″) |
Approval
| Protection | IP66: IEC 60529-2013 |
|---|---|
| Safety | CE-LVD: EN 62368-1: 2014/A11: 2017 |
