Kirjeldus
Base Attributes
| Brand | Hikvision |
|---|---|
| Manufacturer Code | DS-2CD6825G0/C-IVS(2mm)(B) |
| Net Weight | 0.435 |
| Gross Weight | 0.835 |
Key Parameter
| Case type | Specialty |
|---|---|
| Resolutsioon | 2 MP |
| Lens Type | Multi-Lens |
| Low-Light Imaging | Normal |
| Illumination Distance | 0-20m |
| Wireless Network | N/A |
| Storage Type | N/A |
| AI | People Counting |
| Local Output | N/A |
Camera
| Image Sensor | 1/2.7″ Progressive Scan CMOS |
|---|---|
| Min. Illumination | Color: 0.0176 Lux @ (F2.25, AGC ON),B/W: 0.0035 Lux @ (F2.25, AGC ON),B/W: 0 Lux with IR |
| Day & Night | IR cut filter |
Camera Module
| WDR | 120 dB |
|---|
Lens
| Focal Length & FOV | 2 mm, horizontal FOV 104.5°, vertical FOV 70.5°, diagonal FOV 112° |
|---|
Illuminator
| Supplement Light Type | IR |
|---|---|
| Supplement Light Range | Up to 6 m |
Video
| Video Bit Rate | 32 Kbps to 8 Mbps |
|---|---|
| Main Stream | 50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720) |
Network
| Simultaneous Live View | Up to 20 channels |
|---|---|
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| User/Host | Up to 32 users 3 user levels: administrator, operator, and user |
| Client | iVMS-4200,Hik-Connect |
| Security | Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.3, host authentication (MAC address) |
| Day/Night Switch | Day,Night,Auto,Schedule,Alarm Trigger (-S) |
|---|
Interface
| Audio | -S: 1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium, -S: 1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium |
|---|---|
| On-Board Storage | Built-in eMMC storage, up to 8 GB for people counting data |
| Built-in Microphone | Yes |
| Alarm | -S: 1 input(s), 1 output(s) (max. 24 VDC/24 VAC, 1 A) |
Event
| Basic Event | Motion detection,video tampering alarm,network disconnected,IP address conflict,illegal login,HDD full,HDD error |
|---|
Deep Learning Function
| People Counting | Counts people entering and exiting separately Supports real-time uploading and uploading by statistic cycle Sends email reports on daily, weekly, monthly or annually basis Supports target filtering by height |
|---|
General
| General Function | Heartbeat,anti-flicker,mirror,password protection |
|---|---|
| Storage Conditions | -30 °C to 60 °C (-22 °F to 144 °F). Humidity 95% or less (non-condensing) |
| Power Supply | PoE, 12 VDC |
| Startup and Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Dimension | 168 mm × 61 mm × 41 mm (6.6″ × 2.4″ × 1.6″) |
Approval
| Protection | IP67: IEC 60529-2013 |
|---|---|
| Safety | UL: UL 62368-1, CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017, BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005, LOA: IEC/EN 60950-1 |
