Kirjeldus
Base Attributes
| Brand | Hikvision |
|---|---|
| Manufacturer Code | DS-2CD6425G1-20(3.7mm)(8m) |
| Net Weight | 0.145 |
| Gross Weight | 0.827 |
Key Parameter
| Case type | Specialty |
|---|---|
| Resolutsioon | 2 MP |
| Lens Type | Fixed Lens |
| Low-Light Imaging | Normal |
| Illumination Distance | N/A |
| Wireless Network | N/A |
| Storage Type | SD Card |
| AI | N/A |
| Local Output | N/A |
Camera
| Image Sensor | 1/2.8″ Progressive Scan CMOS |
|---|---|
| Min. Illumination | Color: 0.002 Lux @ (F1.2, AGC ON) |
Camera Module
| WDR | 120 dB |
|---|
Lens
| Focal Length & FOV | L10/L20 model: 2.8 mm: horizontal FOV: 93.9°, vertical FOV: 51.7°, diagonal FOV: 109.3° 3.7 mm: horizontal FOV: 75.5°, vertical FOV: 41.6°, diagonal FOV: 87.3° L30 model: 2.8 mm: horizontal FOV: 107.8°, vertical FOV: 57.9°, diagonal FOV: 126.7° 4 mm: horizontal FOV: 82.8°, vertical FOV: 45.1°, diagonal FOV: 98° |
|---|---|
| Iris Type | Fixed |
Video
| Main Stream | 50 Hz: 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 720) |
|---|---|
| Bit Rate Control | CVR/BVR |
Network
| Simultaneous Live View | Up to 15 channels |
|---|---|
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| User/Host | Up to 32 users 3 level: administrator, operator, and user |
| Client | iVMS-4200, Hik-Connect |
| Day/Night Switch | Day, Night, Auto, Schedule |
|---|
Interface
| Audio | 1 input (line in), 1 output (line out) |
|---|---|
| On-Board Storage | Built-in memory card slot, support MicroSD/MicroSDHC/MicroSDXC card, up to 256 GB |
| Alarm | 1 input, 1 output (max. 12 VDC, 30 mA) |
Event
| Basic Event | Motion detection, video tampering alarm, exception (HDD full, HDD error, network disconncected), video quality diagnosis |
|---|---|
| Smart Event | Intrusion detection, line crossing detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection Audio exception detection, defocus detection, scene change detection |
General
| General Function | One-key reset, heartbeat, mirror, password protection, privacy mask, rotate, watermark, IP address filter |
|---|---|
| Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Power Supply | PoE, 12 VDC |
| Startup and Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Dimension | Main body: 77.5 mm × 69 mm × 26 mm (3.1″ × 2.7″ × 1.0″) L10: Ø26 mm × 40 mm (Ø1.0″ × 1.6″) L20: 37 mm × 26 mm × 25 mm (1.5″ × 1.0″ × 1.0″) L30: Ø26 mm × 50 mm (Ø1.0″ × 2.0″) |
Approval
| Safety | UL (UL 62368-1); CB (IEC 62368-1:2014+A11); CE-LVD (EN 62368-1:2014/A11:2017); BIS (IS 13252(Part 1):2010/ IEC 60950-1 : 2005); LOA (IEC/EN 60950-1) |
|---|
